CRI Pumps Dewatering Pump - DM-1M-22-FT/N - 2.20 kW

CRI Pumps Dewatering Pump - DM-1M-22-FT/N - 2.20 kW

(0 review)

Light waste water pumps are designed for pumping waste water from residential and small commercial buildings. These motors are of dry type with E or F class insulation for reliable service and pumps are offered with different type of impellers such as vortex, single channel enclosed, single channel semi open, multi-channel enclosed etc. These pumps are available in both single phase and three phase power supply for continuous duty. Double face mechanical seals ensure reliability and trouble-free service for long life. Few models are supplied with fully stainless steel


General Specifications


Maximum Flow upto 180m³/h
Head upto 56m
Speed2900 RPM
Impeller TypeEnclosed / Semi open Impeller
Outlet Size upto 150mm
Powerupto 15kW
Liquid Temperatureupto 40°C
Max Solid Sizeupto 19mm
Shaft Seal Mechanical Seal
Material of Construction (MOC)Cast Iron & Stainless Steel
Bearing LubricationGrease
Maximum Immersion Depth10m
Maximum Working Pressureupto 5bar


Features


  • Wide hydraulic ranges
  • Heavy duty bearings for long life
  • Dual mechanical seal
  • Stainless steel motor body


Application


  • Dewatering
  • Light sewage handling
  • Waste water transfer
  • Pumping water from pit, trench and basin
  • Flood control
0.00 ZK 0.00 ZK Excl. VAT

  • kW
  • Model
  • Brand
  • Outlet Size
  • Solid Passage
Add to cart
Buy now
Add to wishlist


  • ALL PRODUCTS ARE SUBJECT TO PRIOR SALE - STOCK NOT HELD
  • SUBJECT TO OUR GENERAL TERMS AND CONDITIONS OF SALE
  • ALL INFORMATIONS, DESCRIPTIONS, SPECIFICATIONS,IMAGES, AND TERMS ARE SUBJECT TO BE UPDATED WITHOUT PRIOR NOTCE

Contact Us

Technical Specifications

Model
Model DM-1M-22-FT/N
Power Rating
kW 2.20 kW
Brand
Brand CRI
Others
Outlet Size 3"
Solid Passage 8.5
