C.R.I. Silver line Series deep well / bore hole submersible pumps are multistage centrifugal type supplied with radial or mixed flow engineering thermoplastic impellers and diffusers suitable for 4” diameter borewells. All mounting dimensions are in accordance with NEMA standards.
General Specifications
| Nominal Diameter | 4″/100mm |
| Motor Power Required Ranges | 0.37 – 7.5 kW ,415V, 50HZ 0.37 – 2.2kW, 220V , 50Hz |
| Available Model Ranges | S4P-1, S4P-1E, S4P-2, S4P-3, S4P-4, S4P-5, S4P-8, S4P-10, S4P-14,S4P-18 |
| Maximum Flow Rate | 24 m³/h |
| Maximum Head | 270 m |
| Outlet Sizes | 1¼”, 1½” & 2″ |
Features
- High efficiency
- Stainless steel non return valve and suction inter connector
- Floating impeller for better efficiency
- Can be easily dismantled and repaired
- NEMA mountings
Application
- Residence
- Agriculture
- Gardens
- Sprinkler systems
- Fountains
- Building services
